Gabion: High‑performance Eco‑Engineering Solutions

Shitai Gabions are multi‑functional, environmentally sustainable engineering components constructed from double‑twisted hexagonal woven Wire Mesh containers filled with rock aggregates. As flexible, water‑permeable building units, they are widely adopted for erosion prevention, retaining wall construction, river‑bank reinforcement and slope stabilization works. Produced with premium raw materials including Galfan galvanized wire, hot‑dip galvanized wire and PVC‑coated galvanized wire, our gabions deliver outstanding sturdiness and anti‑corrosion capability, performing reliably even under severe outdoor working conditions.

Product Specifications

Wire Diameter: Optional sizes cover 2.0 mm, 2.2 mm, 2.4 mm, 2.7 mm, 3.0 mm and 3.5 mm up to 4 mm. Mesh Opening Sizes: Standard mesh dimensions are 60×80 mm, 80×100 mm and 100×120 mm; full customisation is supported to match project‑specific demands. Selvage & Lacing Wire: Selvage wire thickness falls within 3‑4 mm, and lacing wire commonly uses 2.0‑2.2 mm specifications. Basket Dimensions: Multiple standard basket sizes are available: 2×1×0.5 m, 2×1×1 m, 3×1×1 m, 4×1×2 m, 4×2×0.23 m, 6×2×0.3 m. Custom‑tailored dimensions are also acceptable according to engineering drawings.

Application and Infrastructure Deployment

Widely recognised as an eco‑friendly material for water conservancy and slope‑protection projects, Shitai Gabions are high‑strength steel wire cages. Once filled with stones, they foster vegetation development and efficiently mitigate soil loss. Apart from conventional hydraulic‑engineering scenarios, their solid mechanical performance and natural visual effect also enable broad application in contemporary infrastructure construction.

For example, they can act as Highway isolation fences and Railway protective fences. Their permeable framework enables natural water drainage, stabilises road embankments and lowers landslide risks. Moreover, gabion retaining walls can be skillfully matched with Sound barriers alongside heavy‑traffic transport routes. When stone‑filled gabion cages are assembled with sound‑absorbing accessories, composite barriers are formed. Such structures suppress traffic‑generated noise efficiently and harmonise with local natural surroundings.

Thanks to superior structural reliability, environmental compatibility and flexible design features, Shitai Gabions serve as a preferred solution for diverse civil‑engineering and landscape‑building assignments.
